User's Manual 23. Routing
Parameter Rule 1 Rule 2 Rule
3
Rule 4 Rule
5
Rule 6 Rule 7 Rule 8
Group
-ZA
Destinatio
n IP
Address
10.33.45.6
3
10.33.45.50
itsp.co
m
0.0.0.
0
10.33.45.6
8
10.33.45.6
7
domain.co
m
IP Profile ABC ABC
Forking
Group
1 2 1
Cost
Group ID
Weekend-
Low
Weekend_Hig
h
Below are descriptions of each rule:

Rules 1 and 2 (Least Cost Routing): For both rules, the called (destination) phone
number prefix is 10, the caller's (source) phone number prefix is 100, and the call is
assigned IP Profile "ABC". However, Rule 1 is assigned a cheaper Cost Group than
Rule 2, and therefore, the call is sent to the destination IP address (10.33.45.63)
associated with Rule 1.

Rule 3 (IP Group destination): For all callers (*), if the called phone number prefix is
20, the call is sent to IP Group "ITSP-ZA".

Rule 4 (domain name destination): For called phone number prefixes 5, 7, 8, or 9,
and the caller belongs to Trunk Group ID 4, the call is sent to the domain "itsp.com".

Rule 5 (block): For all callers (*), if the called phone number prefix is 00, the call is
rejected (IP address 0.0.0.0).

Rule 6, 7, and 8 (Forking Group): For all callers (*), if the called phone number prefix
is 100, the call is sent to Rule 7 and 9 (belonging to Forking Group "1"). If their
destinations are unavailable and alternative routing is enabled, the call is sent to Rule
8 (Forking Group "2").
Table 23-2: Tel-to-IP Routing Table Parameter Descriptions
Parameter Description
Index
[PREFIX_Index]
Defines an index number for the new table row.
Note: Each row must be configured with a unique index.
Name
route-name
[PREFIX_RouteName]
Defines an arbitrary name to easily identify the row.
The valid value is a string of up to 20 characters. By default, no
value is defined.
Note: Each row must be configured with a unique name.
Match
Source Trunk Group ID
src-trunk-group-id
[PREFIX_SrcTrunkGroupID]
Defines the Trunk Group from where the call is received.
To denote any Trunk Group, use the asterisk (*) symbol. By
default, no Trunk Group is defined (-1).
