Version 7.2 511 Mediant 1000B Gateway & E-SBC
User's Manual 24. Manipulation
Action: Defines the action that is done if the incoming call matches the characteristics
of the rule (e.g., removes a user-defined number of digits from the left of the calling
name).
The device searches the table from top to bottom for the first rule that matches the
characteristics of the incoming call. If it finds a matching rule, it applies the manipulation
configured for that rule.
Note: To use the Calling Name Manipulation for Tel-to-IP Calls table for retrieving the
calling name (display name) from an Active Directory using LDAP queries, see
Querying the AD for Calling Name on page 256.
The following procedure describes how to configure calling name manipulation rules
through the Web interface. You can also configure these rules using the the following
management tools:
Calling Name Manipulation for Tel-to-IP Calls table: ini file (CallingNameMapTel2Ip) or
CLI (configure voip > gateway manipulation calling-name-map-tel2ip)
Calling Name Manipulation for IP-to-Tel Calls table: ini file (CallingNameMapIp2Tel) or
CLI (configure voip > gateway manipulation calling-name-map-ip2tel)
To configure calling name manipulation rules:
1. Open the required calling name manipulations table (Setup menu > Signaling &
Media tab > Gateway folder > Manipulation > Calling Name IP->Tel or Calling
Name Tel->IP).
2. Click New; the following dialog box appears:
Figure 24-3: Calling Name Manipulation for IP-to-Tel Calls Table (Example) - Add Dialog Box
3. Configure a manipulation rule according to the parameters described in the table
below.
4. Click Apply.
