Version 7.2 997 Mediant 1000B Gateway & E-SBC
User's Manual 62. Configuration Parameters Reference
Parameter Description
IE of “Voice”, and “Speech” Bearer Capability IE. Note that the
Off Hook Indicator IE is described in UCR 2008 specifications.
- The device interworks the SIP tgrp=hotline-ccdata parameter
(received in INVITE) to ISDN Setup with an Off Hook Indicator
IE of “Data”, and with “Unrestricted 64k” Bearer Capability IE.
The following is an example of the INVITE with tgrp=hotline-
ccdata:
INVITE sip:1234567;tgrp=hotline-ccdata;trunk-
context=dsn.mil@example.com
ISDN-to-IP calls:
- The device interworks ISDN Setup with an Off Hook Indicator
of “Voice” to SIP INVITE with “tgrp=hotline;trunk-
context=dsn.mil” in the Contact header.
- The device interworks ISDN Setup with an Off Hook indicator
of “Data” to SIP INVITE with “tgrp=hotline-ccdata;trunk-
context=dsn.mil” in the Contact header.
- If ISDN Setup does not contain an Off Hook Indicator IE and
the Bearer Capability IE contains “Unrestricted 64k”, the
outgoing INVITE includes “tgrp=ccdata;trunk-context=dsn.mil”.
If the Bearer Capability IE contains “Speech”, the INVITE in this
case does not contain tgrp and trunk-context parameters.
[4] Hotline Extended = Interworks the ISDN Setup message’s
hotline "OffHook Indicator" Information Element (IE) to SIP
INVITE’s Request-URI and Contact headers. (Note: For IP-to-ISDN
calls, the device handles the call as described in option [3].) The
option is applicable only to digital interfaces.
The device interworks ISDN Setup with an Off Hook Indicator
of “Voice” to SIP INVITE Request-URI and Contact header with
“tgrp=hotline;trunk-context=dsn.mil”.
The device interworks ISDN Setup with an Off Hook indicator of
“Data” to SIP INVITE Request-URI and Contact header with
“tgrp=hotline-ccdata;trunk-context=dsn.mil”.
If ISDN Setup does not contain an Off Hook Indicator IE and
the Bearer Capability IE contains “Unrestricted 64k”, the
outgoing INVITE Request-URI and Contact header includes
“tgrp=ccdata;trunk-context=dsn.mil”. If the Bearer Capability IE
contains “Speech”, the INVITE in this case does not contain
tgrp and trunk-context parameters.
Note: IP-to-Tel configuration (using the PSTNPrefix parameter)
overrides the 'tgrp' parameter in incoming INVITE messages.
TGRP Routing Precedence
configure voip > gateway
routing settings > tgrp-
routing-prec
[TGRProutingPrecedence]
Determines the precedence method for routing IP-to-Tel calls -
according to the IP-to-Tel Routing table or according to the SIP 'tgrp'
parameter.
[0] = (Default) IP-to-Tel routing is determined by the IP-to-Tel
Routing table (PSTNPrefix parameter). If a matching rule is not
found in this table, the device uses the Trunk Group parameters for
routing the call.
[1] = The device first places precedence on the 'tgrp' parameter for
IP-to-Tel routing. If the received INVITE Request-URI does not
contain the 'tgrp' parameter or if the Trunk Group number is not
defined, the IP-to-Tel Routing table is used for routing the call.
Below is an example of an INVITE Request-URI with the 'tgrp'
parameter, indicating that the IP call should be routed to Trunk Group
