Data Matrix code
When registered as authorised user, you may use our AUMA Assistant App to scan
the Data Matrix code and directly access the order-related product documents without
having to enter order number or serial number.
Figure 6: Link to AUMA Assistant App:
For further Service & Support, software/apps/... refer to www.auma.com.
2.2. Short description
Multi-turn actuator
Definition in compliance with EN 15714-2/EN ISO 5210:
A multi-turn actuator is an actuator which transmits torque to a valve for at least one
full revolution. It is capable of withstanding thrust.
AUMA multi-turn actuators SA 07.2 – SA 16.2/SAR 07.2 – SAR16.2 are driven by
an electric motor and are capable of withstanding thrust in combination with output
drive type A. For manual operation, a handwheel is provided. Switching off in end
positions may be either by limit or torque seating. Actuator controls are required to
operate or process the actuator signals.
Actuator controls
AM 01.1/AM02.1 actuator controls are used to operate AUMA actuators and are
supplied ready for use.The actuator controls may be mounted directly to the actuator
or separately on a wall bracket.The functions of AM 01.1/AM02.1 actuator controls
include standard valve control in OPEN-CLOSE duty, position indications and different
signals right through to position control (option).
Local controls
Operation (via push-buttons), setting and indication can be performed directly at the
actuator controls (contents of these instructions).
11
SA 07.2 – SA 16.2 /SAR 07.2 – SAR 16.2
AM 01.1/AM 02.1 Identification
