8. Signals (output signals)
8.1. Status signals via output contacts (digital outputs)
The output contacts can be used to indicate operation modes of the actuator or the
actuator controls as binary signals.
The signals are assigned according to the order. Example:
Output contact open = end position CLOSED not reached
Output contact closed = end position CLOSED reached
Collective fault signal
Switches: 1 NC and 1 NO (standard)
Designation in the wiring diagram: K9
The collective fault signal appears if one of the following events occurs (default
configuration):
●
Torque fault: The set torque was exceeded before reaching an end position.
(This signal can be activated/deactivated via a switch in the actuator controls.)
●
Thermal fault: Motor protection has tripped, i.e. the motor is overheated.
●
Phase failure: One phase is missing (3-ph AC motors only).
●
PTC tripping device:Test complete
4 output contacts:
Switches: 1 NC (standard)
Designation in the wiring diagram: K5, K6, K7, K8
Default configuration:
●
K5: Selector switch is in position Remote control (REMOTE).
●
K6: Selector switch is in position Local control (LOCAL).
●
K7: End position OPEN reached (Limit switch OPEN operated)
●
K8: End position CLOSED reached (Limit switch CLOSED operated)
8.2. Optional signals
8.2.1. Analogue signals (analogue outputs)
If the actuator is equipped with a position transmitter (EWG, RWG or potentiometer),
an analogue position feedback signal is available.
Valve position
Signal: E2 = 0/4 – 20 mA (galvanically isolated) with EWG or RWG
Designation in the wiring diagram: E2 (actual value)
38
SA 07.2 – SA 16.2 /SAR 07.2 – SAR 16.2
Signals (output signals) AM 01.1/AM 02.1
