AUMA AM 01.1 User Manual

Weights for multi-turn actuators SA 07.2 – SA 16.2 / SAR 07.2 – SAR 16.2
With DC motors
Weight
2)
Motor type
1)
Type designation
Actuator
approx. [kg]
33FN... 63-...SA 10.2/
SAR 10.2
36FN... 71-...
56FN... 90-...
68FN... 71-... / FN... 80-...SA 14.2/
SAR 14.2
100FN... 90-...
76FN... 80-... / FN... 90-...SA 14.6/
SAR 14.6
122FN... 112-...
123FN... 100-...SA 16.2/
SAR 16.2
Refer to motor name plate1)
Indicated weight includes AUMA NORM multi-turn actuator with DC motor, electrical connection in
standard version, output drive type B1 and handwheel. For other output drive types, heed additional
weights.
2)
Table 7:
Weights for output drive type A 07.2 – A 16.2
[kg]Flange sizeType designation
1.1F07A 07.2
2.8F10A 10.2
6.8F14A 14.2
11.7F16A 16.2
Table 8:
Weights for output drive type AF 07.2 – AF 16.2
[kg]Flange sizeType designation
5.2F10AF 07.2
5.2F10AF 07.6
5.5F10AF 10.2
13.7F14AF 14.2
23F16AF 16.2
3.2. Storage
Danger of corrosion due to inappropriate storage!
→
Store in a well-ventilated, dry room.
→
Protect against floor dampness by storage on a shelf or on a wooden pallet.
→
Cover to protect against dust and dirt.
→
Apply suitable corrosion protection agent to uncoated surfaces.
Damage due to excessively low storage temperatures!
→
AUMA MATIC actuator controls may NOT be stored below –40 °C
Long-term storage
For long-term storage (more than 6 months), observe the following points:
1. Prior to storage:
Protect uncoated surfaces, in particular the output drive parts and mounting
surface, with long-term corrosion protection agent.
14
SA 07.2 – SA 16.2 /SAR 07.2 – SAR 16.2
Transport, storage and packaging AM 01.1/AM 02.1
