AUMA AM 01.1 User Manual

Technical data for handwheel activation switches
10
6
startsMechanical lifetime
Silver plated contacts:
12 V DCU min.
250 V ACU max.
3 A at 250 V (inductive load, cos phi = 0.8)I max. AC current
3 A at 12 V (resistive load)I max. DC current
14.2. Technical data Actuator controls
General information
Actuator controls AM 01.1/AM 02.1 for controlling multi-turn actuators of the SA/SAR .1, SA/SAR .2 type ranges and part-turn actuators of
the SQ/SQR .2 type range.
Features and functions
Refer to name plates at the controls and the motor
Permissible variation of the mains voltage: ±10 %
Permissible variation of the mains frequency: ±5 %
Further permissible fluctuations of mains voltage and frequency (option): (–20 %/+15 %), (–20 %/+10
%), (–30 %/+30 %), , (–30 %/+10 %)
Power supply
(mains voltage, mains frequency)
24 V DC +20 % / –15 %
Current consumption: Basic version approx. 250 mA, with options up to 500 mA
External power supply must have reinforced insulation against mains voltage in accordance with
IEC 61010-1 and may only be supplied by a circuit limited to 150 VA in accordance with IEC 61010-1.
External supply of the electronics
(option)
Current consumption of controls depending on mains voltage:
For permissible variation of mains voltage of ±10 %:
100 to 120 V AC = max. 575 mA
208 to 240 V AC = max. 275 mA
380 to 690 V AC = max. 160 mA
Current consumption
Current consumption for mains voltage variation: > ±10 % on request
Category III according to IEC 60364-4-443Overvoltage category
Rated power
Reversing contactors (mechanically and electrically interlocked) for AUMA power classes
A1/A2
Standard:Switchgear
Reversing contactors (mechanically and electrically interlocked) for AUMA power classes
A1/A2 with additional contacts, 1 NC + 1 NO each
Options:
Reversing contactors (mechanically and electrically interlocked) for AUMA power class
A3
Thyristor unit for mains voltage up to 500 V AC (recommended for modulating actuators)
for AUMA power classes B1, B2 and B3
Reversing contactors are designed for a lifetime of 2 million starts. For applications requiring a high
number of starts, we recommend using thyristor units.
For the assignment of AUMA power classes, refer to the Electric data pertaining to the actuator.
3 digital inputs: OPEN, STOP, CLOSE (via opto-isolator with one common), respect minimum pulse
duration for modulating actuators
Control inputs
(control)
24 V DC, current consumption: approx. 10 mA per inputStandard:Control voltage/current consumption
for control inputs
115 V AC, current consumption: approx. 15 mA per inputOption:
70
SA 07.2 – SA 16.2 /SAR 07.2 – SAR 16.2
Technical data AM 01.1/AM 02.1

AUMA AM 01.1 Specifications

General

Brand	AUMA
Model	AM 01.1
Category	Controller
Language	English
