Cable installation Figure 36: Example of cable installation for actuator controls on wall bracket and
with control box for wall mounting
[1]
Power supply, e.g. 3/PE/400V/50 Hz
[2] Power supply of actuator controls (switchgear control)
[3] Customer connection (XK) control contacts/signals
[4] Motor connection/motor control
[5] Feedback signals from actuator
5.5.2. Parking frame
Figure 37: Parking frame, example with S plug/socket connector and cover
35
SA 25.1 SA 48.1 / SAR 25.1 SAR 30.1
AM 02.1 Electrical connection
