AUMA AM 02.1 User Manual

Accessories
For AM mounted separately from the actuator, including plug/socket connector. Connecting cable on
request. Recommended for high ambient temperatures, difficult access, or heavy vibration during service.
Cable length between actuator and AM max. 100 m. Not suitable for version with potentiometer in the
actuator. Instead of the potentiometer, the actuator has to be equipped with an electronic position
transmitter.
Wall bracket
Further information
Approx. 7 kg (with AUMA plug/socket connector)Weight
Electromagnetic Compatibility (EMC): (2014/30/EU)
Low Voltage Directive: (2014/35/EU)
Machinery Directive: (2006/42/EC)
EU Directives
14.3. Technical data Control box
G7G5G3Size
760 x 760 x 300 mm500 x 500 x 210 mm380 x 380 x 210 mmDimensions (w x h x d):
A4 Wide range voltage, A4 with
disconnect switch
–A4SA 07.2 – 16.2,
3ph
Suitable for utiliz-
ation category
A2/A4/A5 with R
A
1)
, A6A5A4 only in 24 V DC versionSA 07.2 – 16.2,
DC
A4/A5 Wide range voltage, A4/A5
with disconnect switch A6
A5A4SA 25.1 – 48.1,
3ph
Starting resistance1)
Features and functions
Refer to name plateMains voltage, mains frequency
Thermoswitches with automatic reset
Thermal overload relay with manual reset
3-phase AC
current: (op-
tion)
Motor protection
Thermal overload relay with manual resetDC current:
(standard)
Disconnect switchSpecial components (option)
M25, 2 x M40 including cable glandsThreads for cable entries
Refer to name plateTerminal plan
●
From control box to actuator
Cable length from 2 – 28 m, state desired length in the order
●
From control box to actuator controls
Cable length from 2 – 100 m, state desired length in the order
Connecting cables (option)
Category III according to IEC 60364-4-443Overvoltage category for 3-phase
AC current
Service conditions
Indoor and outdoor use permissibleUse
SuspendedMounting position
–20 °C to +60 °CAmbient temperature
Up to 100 % relative humidity across the entire permissible temperature rangeHumidity
IP66Enclosure protection according to
EN 60529
KS, steel, colour R7035 light grey, powder coatingStandard:Corrosion protection, housing mater-
ial, colour, finish coating
Available colours on request
KX, stainless steel
Option:
Suitable for use in areas with high salinity, almost permanent condensation, and high
pollution.
KS
Suitable for use in areas with extremely high salinity, permanent condensation, and high
pollution.
KX
77
SA 25.1 – SA 48.1 / SAR 25.1 – SAR 30.1
AM 02.1 Technical data
