AUMA AM 02.1 User Manual

Electromechanical control unit
Counter gear mechanism for end positions OPEN and CLOSED
Turns per stroke: 2 to 500 (standard) or 2 to 5,000 (option)
Limit switching
Single switch (1 NC and 1 NO) for each end position, not galvanically isolatedStandard:
Tandem switch (2 NC and 2 NO) for each end position, switches galvanically isolated
Triple switch (3 NC and 3 NO) for each end position, switches galvanically isolated
Intermediate position switches (DUO limit switching), adjustable for each direction of op-
eration
Options:
Torque switching adjustable for directions OPEN and CLOSETorque switching
Single switch (1 NC and 1 NO) for each direction, not galvanically isolatedStandard:
Tandem switch (2 NC and 2 NO) for each direction, switches galvanically isolatedOptions:
Silver (Ag)Standard:Switch contact materials
Gold (Au), recommended for low voltage actuator controlsOption:
Potentiometer or 0/4 – 20 mA (electronic position transmitter)Position feedback signal, analogue
(option)
Continuous indication, adjustable indicator disc with symbols OPEN and CLOSEDMechanical position indicator (op-
tion)
Blinker transmitter (optional for modulating actuators)Running indication
Self-regulating PTC heater, 5 – 20 W, 110 – 250 V AC/DCStandard:Heater in switch compartment
24 – 48 V AC/DC (for actuators with 3-phase AC/1-phase AC/DC motors)
or 380 – 400 V AC/DC (for actuators with 3-phase AC motors)
Options:
A resistance type heater of 5 W, 24 V AC is installed in the actuator in combination with AM or AC actu-
ator controls.
Service conditions
Indoor and outdoor use permissibleUse
Any positionMounting position
≤ 2,000 m above sea level
> 2,000 m above sea level on request
Installation altitude
–30 °C to +70 °CStandard:Ambient temperature
–40 °C to +80 °C (multi-turn actuators for open-close duty)
–40 °C to +70 °C (multi-turn actuators for modulating duty)
–50 °C to +60 °C
–60 °C to +60 °C
0 °C to +120 °C (multi-turn actuators for open-close duty)
Temperatures exceeding +70 °C on request (multi-turn actuators for modulating duty)
Options:
For exact version, refer to actuator name plate.
Up to 100 % relative humidity across the entire permissible temperature rangeHumidity
IP67 with AUMA 3-phase AC motor
For special motors, differing enclosure protection is possible
Standard:Enclosure protection according to
EN 60529
●
IP68 with AUMA 3-phase AC motor
●
DS terminal compartment additionally sealed against interior of actuator (double
sealed)
Option:
According to AUMA definition, enclosure protection IP68 meets the following requirements:
●
Depth of water: maximum 8 m head of water
●
Duration of continuous immersion in water: Max. 96 hours
●
Up to 10 operations during continuous immersion
●
Modulating duty is not possible during continuous immersion.
For exact version, refer to actuator name plate.
Pollution degree 4 (when closed), pollution degree 2 (internal)Pollution degree according to IEC
60664-1
2 g, from 10 to 200 Hz (for actuators in AUMA NORM version)
1 g, for 10 to 200 Hz (for actuators with AM or AC integral actuator controls)
Resistant to vibration during start-up or for failures of the plant. However, a fatigue strength may not be
derived from this. Indiations apply to actuators with AUMA 3-phase AC motor and AUMA plug/socket
connector.They are not valid in combination with gearboxes.
Vibration resistance according to
IEC 60068-2-6
73
SA 25.1 – SA 48.1 / SAR 25.1 – SAR 30.1
AM 02.1 Technical data
