Please state device type and our order number (see name plate) when ordering spare parts. Only original AUMA spare parts should be used.
Failure to use original spare parts voids the warranty and exempts AUMA from any liability. Representation of spare parts may slightly vary
from actual delivery.
TypeDesignationRef. no.TypeDesignationRef. no.
Screw plug539.0Sub-assemblyHousing001.0
Sub-assemblyHandwheel with ball handle542.0Sub-assemblyBearing flange002.0
Sub-assemblyOutput drive type B3/B4549.0Sub-assemblyHollow shaft003.0
Sub-assemblyOutput drive sleeve B3/B4549.1Drive shaft005.0
Parallel key551.1Motor coupling005.1
Mechanical position indicator553.0Sub-assemblyCoupling pin005.2
Sub-assemblyPotentiometer as position transmitter556.0Manual drive coupling005.3
Sub-assemblyPotentiometer without slip clutch556.1Sub-assemblyPull rope005.4
Heater557.0Worm wheel006.0
Sub-assemblyBlinker transmitter including pins at wires
(without impulse disc and insulation plate)
558.0Sub-assemblyManual gearing009.0
Sub-assemblyElectromechanical control unit with
switches, including torque switching heads
559.0–1Sub-assemblyTorque lever017.0
Sub-assemblyElectronic control unit with magnetic limit
and torque transmitter (MWG)
559.0–2Antriebsrad Drehmomentschaltung018.0
Sub-assemblySwitch stack for direction OPEN560.0Crown wheel019.0
Sub-assemblySwitch stack for direction CLOSE560.0Swing lever020.0
Sub-assemblySwitch for limit/torque560.1Drive pinion II for torque switching022.0
Switch case560.2Sub-assemblyOutput drive wheel for limit switching023.0
Sub-assemblyRWG position transmitter566.0Sub-assemblyDrive wheel for limit switching024.0
Potentiometer for RWG without slip clutch566.1Sub-assemblyLocking plate025.0
Sub-assemblyPosition transmitter board for RWG566.2Sub-assemblyCable for protective earth058.0
Sub-assemblyCable set for RWG566.3Sub-assemblyMotor070.0
Slip clutch for potentiometer567.1Sub-assemblyPlanetary gearing for motor drive (for A...
motor)
080.0
Stem protection tube (without cap)568.1Sub-assemblyReduction gearing155.0
Protective cap for stem protection tube568.2Sub-assemblyCover500.0
V-seal568.3Sub-assemblySocket carrier (complete with sockets)501.0
Threaded sleeve (for SA/SAR 25.1 and
30.1)
568.4Sub-assemblyPin carrier without pins502.0
Sub-assemblyChange-over lever assy569.0Sub-assemblySocket for controls503.0
Change-over lever569.1Sub-assemblySocket for motor504.0
Notched pin569.2Sub-assemblyPin for controls505.0
Stem nut (without thread)575.1Sub-assemblyPin for motor506.0
Reduction frame602.0Sub-assemblyCover for electrical connection507.0
Sub-assemblyMotor connection603.0Sub-assemblyThreaded plug511.0
Sub-assemblyEWG position transmitter614.0Sub-assemblyOutput drive type A (without stem nut)514.0
MWG 05.03 cover627.0Sub-assemblyAxial needle roller bearing514.1
SetSeal kit, smallS1Radial seal for output drive type A514.2
SetSeal kit, largeS2Snap ring535.1
80
SA 25.1 – SA 48.1 / SAR 25.1 – SAR 30.1
Spare parts AM 02.1
