Actuator controls AUMATIC AC 01.1 / ACExC 01.1
DeviceNet Operation instructions
12
Transmission rate
Number of devices Up to 64 DeviceNet devices can be connected
Bus access Data exchange by polling or via Explicit Messages.
Supported DeviceNet functions Group 2 only Server
Predefined Master/Slave Connection Set
- Explicit Connection
- I/O Poll Connection
- Fragmentation is supported
Device Heartbeat Message
Device Shutdown Message
Offline Connection Set
Service conditions
Enclosure protection according
to EN 60 529
Standard: IP 67 (when mounted)
Options: IP 68
7)
Terminal compartment additionally sealed against interior (double sealed)
Corrosion protection Standard: KN suitable for installation in industrial units, in water or power plants
with a low pollutant concentration
Options: KS suitable for installation in occasionally or permanently aggressive
atmosphere with a moderate pollutant concentration
(e.g. wastewater treatment plants, chemical industry).
KX suitable for installation in extremely aggressive atmosphere with high
humidity and high pollutant concentration
Finish coating Standard: two-component iron-mica combination.
Option: Special primer / special finish coat (customer’s choice)
Colour Standard: silver-grey (DB 701, similar to RAL 9007)
Option: Other colours as standard colour are possible on request
Ambient temperature – 25 °C to + 70 °C
Vibration resistance
according to IEC 60 068
1 g, from 10 Hz to 200 Hz
Weight approx. 7 kg (including AUMA plug/ socket connector)
Accessories
Wall bracket
8)
AUMATIC mounted separately from the actuator, including plug/ socket connector.
Connecting cables on request.
Recommended for high ambient temperatures, difficult access or in case of heavy
vibrations during service.
EMERGENCY STOP button
9)
The control voltage of the reversing contactors is interrupted by operating the
EMERGENCY STOP button
Programming software COM-AC incl. interface cable
Other information
EU Directives Electromagnetic Compatibility (EMC): (89/336/EEC)
Low Voltage Directive: (73/23/EEC)
Machinery Directive: (98/37/EC)
Reference documents: Product description “Actuator controls AUMATIC AC”
Dimension sheets Multi-turn actuators/ part-turn actuators “with integral controls AUMATIC
AC”
4) Requires position transmitter in the actuator
6) The internal drop line length of an AUMATIC is 0.27 m
7) For version in enclosure protection IP 68 higher corrosion protection KS or KX is strongly recommended
8) Distance between actuator and AUMATIC max. 100 m. Not suitable for version with potentiometer in the actuator. Instead of the potentiometer, a RWG has to be
used. Cable length for Non-intrusive version with MWG in the actuator max. 100 m. Requires separate data cable for MWG. If actuator and AUMATIC are
separated at a later date the max. cable length is 10 m.
9) Only in combination with reversing contactors and AUMATIC AC 01.1 in enclosure protection IP 67 or IP 68
Baud rate
Maximum
trunk line length
Minimum
accumulated
drop line length
6)
Maximum
single
drop line length
6)
Thick Cable Thin Cable
125 kByte 500 m 100 m 156 m 6 m
250 kByte 250 m 100 m 78 m 6 m
500 kByte 100 m 100 m 39 m 6 m
