Actuator controls AUMATIC AC 01.1 / ACExC 01.1
DeviceNet Operation instructions
Subgroup Parameter
name
Sub
menu
Standard
value
Min/
Max
Valuetext
Note
M1M DEVICE-
NET 1
BAUDRATE
SW.VALUE
M1MX0
30
125KBAUD
Baud rate; change via local con
-
trols possible, use PGM MODE to
activate the baud rate setting via
DeviceNet (in this case, the Devi-
ceNet baud rate can be defined
via the Explicit Messages of the
process control system). AUTO
activates the automatic baud rate
detection. In order to detect a new
baud rate, the AUMATIC has to
be switched off for a short time.
As an alternative, you may also
disconnect DeviceNet power
supply
1)
.
1
250KBAUD
2
500KBAUD
3
PGM MODE
4
AUTO
MAC ID SW.
VALUE
M1MX2
64 0- 64
0-64
Actuator address; changes possi-
ble via local controls. Address 63
must not be used since this is the
default address for all DeviceNet
devices. Use address 64 to
enable the MAC ID setting via
DeviceNet (in this case the Devi-
ceNet address can be defined via
Explicit Messages of the process
control system); in addition, the
OFFLINE CONNECTION SET is
activated. This can be used to
reconnect a DeviceNet device
after a COMMUNICATION
FAULT STATE (due to a dupli-
cate MAC ID or a bus-off status)
to the DeviceNet network
1)
.
SELECTED CON-
SUMED PATH
M1M05
31
STANDARD
OUTPUT
Connection path for data which
are 'consumed' by the actuator
(refer also to above description of
the output data, page 33).
2
STANDARD
1.AN OUT
3
PROCESS
OUTPUT
1) After having changed this parameter, the AUMATIC must be switched off for a short time. As an alternative, you may also disconnect the 24 V DC DeviceNet
voltage supply for a short time.
