300-002547-00 rev7 47
13. Press Start Procedure to continue.
NOTE: Ensure fluoroscopy system has a minimum clearance distance of 70 cm
vertically and laterally from the Field Generator. To do so may affect the
measurement volume, contributing to inaccurate transformations.
NOTE: In larger patients, it may be difficult for all three sensors to turn green. In
this case, the sensor furthest away from the Field Generator should be the one
designated as yellow or orange. Yellow, orange, and red indicate that portions
of the lung may have sequentially less accurate navigational targeting.
