60 300-002547-00 rev7
Top Navigation Bar
Item Description
Menu icon
High Beam icon appears when the Light button is pressed.
The feature increases light emission from the tip.
Irrigation indicator: Estimated total volume delivered from the
pump is displayed. Text turns blue when irrigation is active.
Aspiration icon: Appears when aspiration is active.
Irrigation icon: Appears when irrigation is active.
This text reflects the distance to from the tip to the nodule.
Primary Area
Any of the views from the center column can be selected using either the
Touchscreen or the select button on the Monarch Controller to “promote” the
view to the larger window.
