80 300-002547-00 rev7
insertion bar here indicates how much you have advanced beyond the Monarch
Bronchoscope Sheath.
Drive Modes
Drive Mode Description
Paired
When the scope/sheath tips are flush and the Paired icon appears, both
devices will insert and retract together. Articulation will command the sheath
articulation. Scope articulation will follow the sheath. In paired position, the
scope is extended 5mm out of the sheath.
Autorelax
If the scope or sheath is retracted for >25mm without any additional
articulation commanded, the device will automatically relax.
Autopair If the sheath is advanced up to the scope, it will automatically pair with the
scope. If the scope is retracted into the sheath, the scope will automatically
pair with the sheath. Pairing has a momentary delay (1.5 seconds) to
prevent inadvertent pairing.
Perform Biopsy
WARNING: Ensure fluoroscopy system is operating properly and does not
interfere with the Monarch Platform before patient use.
NOTE: Do not irrigate with working instruments in the working channel. This can
cause pressure build up in the irrigation tubing.
Monarch Controller
You do not have to hold the Monarch Controller while taking biopsies. If you
decide to place the Monarch Controller down, press the pause button. This will
prevent any accidental manipulation. The Monarch Controller is also equipped
with an accelerometer if it is accidentally dropped or knocked off the table. This
automatically disables it. Pause the Monarch Controller and place it aside before
continuing with the biopsy.
Lavage
If you want to perform a lavage, you must disconnect the valve on the backend of
the Monarch Bronchoscope and access the working channel with a syringe.
