300-002547-00 rev7 33
Touchscreen Item Mouse Action Description
Add
Click a point in the
segmentation screen.
Add multiple points to create a manual path.
Delete
N/A Deletes a point that you inserted.
Close
Click Close. Exits the Manual Path screen.
Segmentation Review
WARNING: Ensure that the segmentation generated from the CT scan
accurately identifies the airways. Poor segmentation representation may result
in incorrect navigational guidance. Failure to exercise clinical judgment and
endoscopic view to determine appropriate navigation and biopsy plan may
result in biopsy of unintended location.
Automatic Path Adjustments
Any auto generated path can be manually adjusted or manipulated by selecting
and dragging the automatic path to the new location where segmentation exists.
This can be performed in the Segmentation Review screen only.
Before You Can Plan
1. Prior to planning, the patient you are working with is required to be CT
scanned. Refer to the Recommended CT Scan and Reconstruction
Parameters (page 24) for optimal results.
2. Save CT scan to disk.
Create a Plan
NOTE: Multiple CT scans will result in multiple patient cases for the same patient.
1. Log on to the Monarch Pre-Op Planning Application.
2. Click or tap Import DICOM. The DICOM loads from the disk and creates a
new Patient Case from this.
3. Click or tap the patient case to expand the menu and show additional patient
and CT Data information. CT Data includes spacing between slices, slice
thickness, and number of slices for the patient case.
