EA1-TCL-M Hardware User Manual, 2nd Ed., 10/10
1–7
Chapter 1: Getting Started
1
Quick Start Steps
Step 1 – Unpack and Inspect
a.) Unpack the C-more Color Micro-Graphic panel from its shipping carton. Included in the
carton are the following:
• C-more Color Micro-Graphic panel
• DC power connector
• cutout template
• mounting clips
• gasket
• function key label inserts
• Quick Start Guide
b.) Unpack any accessories that have
been ordered, such as:
Keypad Bezel, programming
cable, PLC communications
cable, etc.
c.) Inspect all equipment for
completeness. If anything is
missing or damaged,
immediately call the
AutomationDirect
®
returns
department @ 1-800-633-0405.
Shipping Carton Contents
To Next Page
