NOTE: See Chapter 6: PLC Communications for a detailed chart of PLC compatibility & cable connections.
Chapter 6 includes wiring diagrams for end user construction of certain cables.
Available purchased cables
Cable Description Cable Part No.
Cables used with serial Port2
AutomationDirect Productivity Series,
CLICK,
Direct
LOGIC PLC RJ-12 port,
DL05, DL06, DL105, DL205, D3-350, D4-
450 & H2-WinPLC (RS-232C)
EA-2CBL
Direct
LOGIC (VGA Style) 15-pin port,
DL06, D2-250 (250-1), D2-260
(RS-232C).
EA-2CBL-1
Direct
LOGIC PLC RJ-11 port, D3-340
(RS-232C).
EA-3CBL
Direct
LOGIC DL405 PLC 15-pin D-sub
port, DL405 (RS-232C).
EA-4CBL-1
Direct
LOGIC PLC 25-pin D-sub port,
DL405, D3-350, DL305 DCU and all DCM’s
(RS-232C).
EA-4CBL-2
Allen-Bradley MicroLogix 1000, 1100,
1200 & 1500 (RS-232C)
EA-MLOGIX-CBL
Allen-Bradley SLC 5-03/04/05,
ControlLogix, CompactLogix, FlexLogix
DF1 port (RS-232C)
EA-SLC-232-CBL
Allen-Bradley PLC-5 DF1 port
(RS-232C)
EA-PLC5-232-CBL
Allen-Bradley MicroLogix, SLC 5-01/02/03,
PLC5 DH485 port (RS-232C)
EA-DH485-CBL
GE 90/30, 90/70, Micro 90, Versamax
Micro (Port2) 15-pin D-sub port
(RS-422A)
EA-90-30-CBL
MITSUBISHI FX Series 25-pin port
(RS-422A)
EA-MITSU-CBL
MITSUBISHI FX Series 8-pin mini-DIN
(RS-422A)
EA-MITSU-CBL-1
OMRON Host Link (C200 Adapter, C500)
(RS-232C)
EA-OMRON-CBL
PLC Drivers
Serial - port2 only
AutomationDirect Productivity Series Allen-Bradley DF1 Full Duplex
AutomationDirect CLICK Allen-Bradley PLC5 DF1
AutomationDirect K-sequence Allen-Bradley DH485
AutomationDirect DirectNET GE SNPX (90/30, 90/70, Micro 90, VersaMax Micro)
AutomationDirect Modbus Mitsubishi FX
AutomationDirect SOLO Mitsubishi (Q, QnA)
AutomationDirect GS Drives Omron Host Link (C200 Adapter, C500)
Modicon Modbus RTU Omron FINS Serial (CJ1, CS1)
Entivity Modbus RTU Siemens PPI (S7-200 CPU)
Allen-Bradley DF1 Half Duplex
Available PLC Protocols
