DirectLOGIC PLCs Password Protection
NOTE: DirectLOGIC PLCs support multi-level password protection of the ladder program. This allows
password protection while not locking the communication port to an operator interface. The multilevel
password can be invoked by creating a password with an upper case "A" followed by any variation of seven
numeric characters (e.g. A1234567). Please refer to the specific PLC user manual for further details.
Compatibility and Connection Charts
The following pages include charts that list the recommended cables and/or manufactured
devices that can be used to make up the communications link between several different
controllers and the C-more Micro-Graphic panel. Port2 is a 15-pin D-sub communication port
that supports RS-232, RS-485 and RS-422. An external 1 Amp @ 12-24 VDC external power
source is required.
Note: Recommended DC power supply to power the C-more Micro-Graphic Panel, AutomationDirect Part
No. PSP24-024S or PSP24-024C.
The chart also refers to wiring diagrams that can be used to construct cables for connecting the
PLC’s port to the panel’s port. The use constructed cable disgrams start on page 6-24.
6–5
Chapter 6: PLC Communications
EA1-TCL-M Hardware User Manual, 2nd Ed., 10/10
