21-Button Portrait (Vertical) Keypad Bezel for 6-inch Panels
The 21-button keypad bezel is designed to be used with the C-more 6” Micro-Graphic panels.
The keypad includes four directional arrow cursor buttons, a full numeric keypad, and one each
of an ESCAPE, MENU, CLEAR and two ENTER buttons. The keypad is intended to be used
with the numeric entry object to allow changing of a value, and can also be used to navigate &
select screen objects. The numeric buttons can be used to enter a new value, or use the cursor
left and right buttons to select a digit and the cursor up and down buttons to change the value,
along with the ENTER and CLEAR buttons. It can also be used to access and navigate the
screen selector feature. The keypad bezel is designed for easy drop-in of a
C-more 6” Micro-Graphic panel. No panel configuration is required.
