EA1-T4CL Panel Dimensions
2–7
Chapter 2: Specifications
2
EA1-TCL-M Hardware User Manual, 2nd Ed., 10/10
®
Panel Dimensions
Units: Inches [mm]
Enclosure Thickness Mounting Clip Screw Torque
.34
[8.7]
1.25
[31.8]
1.81
[45.9]
2.04
[51.7]
GASKET
MOUNTING CLIP
(4) places
4.31
[109.5]
3.58
[91.0]
4.36
[110.8]
3.58
[91.0]
ND CONT.EQ.
7M17
MODEL EA1-T4CL
Da e code 9048
MADE IN CHINA
INPUT:12 24V 0 19 0 38A Cla s2
EA1 T4CL＋094018001
53 1 R**.
MOUNTING CLIP
SCREW TORQUE RANGE
21 - 28 oz-in [0.15-0.2 Nm]
ENCLOSURE MOUNTING
THICKNESS RANGE
0.04” - 0.2” [1 - 5mm]
