Autonics TK Series User Manual

6 Parameter Settings and Functions
70 © Copyright Reserved Autonics Co., Ltd.
 ④, ⑧: Select the digit and configure the desired MV value using the keys
moving to 0→1→2→3→4→5→6→7→8→9→0 by the keys.
 ⑨: In ① to ⑧ status, press the key(the key for TK4N, TK4S, TK4SP
model) to end manual control. The MAN indicator goes off and the system reverts to
auto control mode.
(2) Manual control switching for heating & cooling control
 ①: When in RUN mode, press the key (the key for TK4N, TK4S, TK4SP
model) and it enters heating MV monitoring mode. The SV display shows ‘H’ and
shows MV to indicate the start of heating MV monitoring.
 ②: If the is pressed when heating MV monitoring is in progress, the MAN
indicator comes on and the lowest digit (10
0
digit) starts to flash, indicating activation of
manual control.
 ③: Press the key to change the flashing digit (10
0
→ 10
1
→ 10
2
→ 10
3
→ 10
0
).
 ④: Select the digit and configure the desired MV value using the keys
moving to 0→1→2→3→4→5→6→7→8→9→0 by the keys.
 ⑤: In ① to ④ status, press the key( key for N, S, SP model) and it enters
cooling MV monitoring mode. The SV display shows ‘C’ and shows MV to indicate the
start of cooling MV monitoring.
 ⑥: If the is pressed when cooling MV monitoring is in progress, the lowest
digit (10
0
digit) starts to flash.

⑦: Press the key to change the flashing digit (10
0
→ 10
1
→ 10
2
→ 10
3
→ 10
0
).
 ⑧: Select the digit and configure the desired MV value using the keys
moving to 0→1→2→3→4→5→6→7→8→9→0 by the keys.
 ⑨: In ⑤ to ⑧ status, press the key(the key for TK4N, TK4S, TK4SP
model) to end manual control. The MAN indicator goes off and the system reverts to
auto control mode.
After heating & cooling control, the system reverts to auto control in sequence of heating
monitoring, manual heating control, cooling monitoring, and manual cooling control.
Heating MV remains in effect during cooling monitoring and manual cooling control.
TK4N/S/SP (W48×H48mm) does not have the key. Press the key once to change
between auto and manual controls.
If the digital Input [DI-1, DI-2] feature has been set for AUTO/MANUAL, the key ( the
key for TK4N, TK4S and TK4SP model) key located on the front and automatic/manual
control functions via communication do not act.
(3) Manual/Auto Control switching with the digital input (DI) terminal
If the digital Input (DI) feature has been configured for manual/auto control switching, turn
on the DI to activate manual control (MAN indicator goes on) and turn off the DI to activate
auto control. If the digital Input feature is automatic control status, you can be only to
monitor. In case it is manual control status, modifying MV and monitoring are possible.
See 6.7.4 Digital input, for detailed information on digital Input (DI) terminal settings.
When MV parameter is masked, MV parameter cannot be monitored and changed.
