Autonics TK Series User Manual

6 Parameter Settings and Functions
© Copyright Reserved Autonics Co., Ltd. 71
6.2.4.2 Baseline MV for manual control [PAR5 → ItMV]
When switching from auto control [AUTO] to manual control [PrMU] you can set the initial MV.
 AUTO: Controlling with auto control MV as an initial MV for manual control
 PrMV: Controlling with preset manual MV [PrMV] as an initial MV.
Auto-MV[AUTO]
Preset MV[PrMV]
Setting
group
Parameter Setting range Factory default Unit
PAR5 ItMV AUTO / PrMV AUTO -
When re-supplying the power, it controls with the MV which is at the power OFF.
6.2.4.3 Initial MV for manual control [PAR5 → PrMV]
If the baseline MV for manual control is configured to PrMV (Preset Manual MV), you can set the
initial MV for manual control.
Setting
group
Parameter Setting range
Factory
default
Unit
PAR5 PrMV
Standard
control
ON/OFF
control
00)0 (OFF)
/10)0 (ON)
00)0 %
PID
control
00)0 to10)0
Heating
&
Cooling
control
ON/OFF
control
`0)0 (Cooling ON)
/ 00)0(OFF)
/10)0 (Heating ON)
PID
control
`0)0 (Cooling) to
00)0 (OFF) to
10)0 (Heating)
When in heating & cooling control mode, a setting between )1 and 10)0 will be applied as
heating MV and a setting between )1 and `0)0 will be applied as cooling MV.
