BS100 DYFI Operators handbook
P-BS100/FE - Rev.F / Doc/ 980114 49 Autronica Fire and Security AS
C.1 Alarm /Prewarning / Fault /More alarms
BU-units can be programmed to present fire alarm, prewarning and fault
with text on the display.
C.1.1 Fire alarm from a BS-100
Fire alarm message (panel address, loop, detector no. or custom text) will
only appear in the display of the BS-100 control panel which has registered
the incident and on the BU-units.
BU-100 will present alarm from all detectors, BU-70 and BU-101 can be
programmed into presentation zones.
Fire alarm message will only appear in the display of the BS-100 control
panel even if the door is open.
Internal buzzer and FIRE indication lamps will be activated on the BS-100
control panel which registered the fire alarm and on the BU-units.
Only the BMA-output on the control panel which registered the fire alarm
will be activated.
Only the control outputs on the BS-100 control panel which registered the
fire alarm will be activated.
Only the sounders connected to the control panel which registered the fire
alarm will be activated.
Alarm output on the EA- will be activated (output L57).
C.1.2 Prewarning
Prewarning message (panel address, loop, detector no. or custom text) will
only appear in the display of the BS-100 control panel which registered the
prewarning and on the BU-units.
If the front door is open on the BS-100 control panel, there will be no
message in the display or transmitted to the BU-units. The message will
appear when the door is closed.
Internal buzzer and PREWARNING indication lamps will be activated on
the BS-100 control panel which registered the prewarning and on the BU-
units.
Only the BMFO-output on the control panel which registered the
prewarning will be activated.
Prewarning output on the EA- will be activated (output L58).
!
