5 Drive bay 4
6 Power control button and LED
7 Operator information panel
8 Operator information panel release latch
9 Video connector
10 USB connector 1
11 Rack release latch
12 USB connector 2
13 DVD eject button
14 DVD drive activity LED
15 DVD drive
16 Drive bay 5
17 Drive bay 3
18 Drive bay 1
19 Rack release latch
Back of server
1
PCIe slot 1 (used for optional Ethernet connectors 5 and 6)
2 Ethernet activity LED
Server installation and connectivity
38 Installing and Configuring Avaya Aura
™
System Platform April 2010
