Chapter 5. DETAILED DESCRIPTION OF EACH FUNCTION

Setting example
• Event
Event Display Internal Event 1 Internal Event 2
Operation type
E
_
.C1
9: Deviation high/low
limit (Final SP reference)
32: Timer (Status)
Direct/reverse
E
_
.C2
1: Reversed. ----
Standby
E
_
.C2
0: No standby ----
EVENT state at READY
E
_
.C2
1: EVENT state at READY is
forcibly turned OFF.
0: EVENT state at READY is
continued.
Alarm OR
E
_
.C3
0: None 0: None
Special OFF setup
E
_
.C3
0: As usual. ----
Delay time unit
E
_
.C3
0: 0.1s 0: 0.1s
Event main setting
(low limit)
E
_
3 ----
Event sub setting
(high limit)
E
_
.SB
3 ----
Hysteresis
E
_
.HY
9999 ----
ON delay
E
_
.ON
2 15
OFF delay
E
_
.OF
0 0
Note. The internal event No. is indicated at the mark of "_" shown in the display
column.
• DI Assignment
DI Assignment Display Internal Contact 1 Internal Contact 2
Operation type
DI
_
.1
7: RUN/READY 17: Timer stop/start
Input bit function
DI
_
.2
1: Function 1 (A and B) or
(C and D)
1: Function 1 (A and B) or
(C and D)
Input assignment A
DI
_
.3
18: COM DI 1 10: Internal Event 1
(Setting = 9: Deviation
high/low limit (Final
SP reference)
Input assignment B
DI
_
.4
11: Internal
Event 2 (Setting = 32:
Timer (Status))
26: During SP ramp
Input assignment C
DI
_
.5
0: Normally opened.
(Normally Off = 0)
18: COM DI 1
Input assignment D
DI
_
.6
0: Normally opened.
(Normally Off = 0)
11: Internal Event 2
(Setting = 32:
Timer (Status))
Polarity A
DI
_
.7
0: Direct 0: Direct
Polarity B
DI
_
.7
1: Reverse 1: Reverse
Polarity C
DI
_
.7
0: Direct 0: Direct
Polarity D
DI
_
.7
0: Direct 0: Direct
Polarity
DI
_
.8
1: Reverse 0: Direct
Event channel
definitions
DI
_
.9
---- 2
Note. The internal DI No. is indicated at the mark of "_" shown in the display
column.
