Chapter 6. LIST OF DISPLAYS AND SETTING DATA
Event bank
Bank selection:
Display Item Contents
Initial
value
User
level
Notes
Internal Event 1
main setting
-1999 to +9999
The decimal point position may vary
so that it meets the operation type
of the internal event.
The above value becomes 0 to 9999
in some operation types.
0
0
Necessary settings are
displayed according to
Internal Event 1 Configuration
(
E1.C1
).
Internal Event 1
sub-setting
0 0
Internal Event 1
Hysteresis
0 to 9999
The decimal point position may vary
so that it meets the operation type of
the internal event.
5
0
Internal Event 1
ON delay time
0.0 to 999.9
(Delay unit is 0.1 s.)
0 to 9999
(Delay unit is other than 0.1 s.)
0
2
Internal Event 1
OFF delay time
0
2
Internal Event 2
main setting
Same as Internal Event 1. 0
0
Necessary settings are
displayed according to
Internal Event 2 Configuration
(
E2.C1
).
Internal Event 2
sub-setting
0
0
Internal Event 2
Hysteresis
5
0
Internal Event 2
ON delay time
0
2
Internal Event 2
OFF delay time
0
2
Internal Event 3
main setting
Same as Internal Event 1. 0
0
Necessary settings are
displayed according to
Internal Event 3 Configuration
(
E3.C1
).
Internal Event 3
sub-setting
0
0
Internal Event 3
Hysteresis
5
0
Internal Event 3
ON delay time
0
2
Internal Event 3
OFF delay time
0
2
Internal Event 4
main setting
Same as Internal Event 1. 0
0
Necessary settings are
displayed according to
Internal Event 4 Configuration
(
E4.C1
).
Internal Event 4
sub-setting
0
0
Internal Event 4
Hysteresis
5
0
Internal Event 4
ON delay time
0
2
Internal Event 4
OFF delay time
0
2
Internal Event 5
main setting
Same as Internal Event 1. 0
0
Necessary settings are
displayed according to
Internal Event 5 Configuration
(
E5.C1
).
Internal Event 5
sub-setting
0
0
Internal Event 5
Hysteresis
5
0
Internal Event 5
ON delay time
0
2
Internal Event 5
OFF delay time
0
2
