Revision History of CP-SP-1150E
Date Rev. Revised pages Description
Feb. 2004 1
Oct. 2004 2
1-2, 4-3, 13-5
1-7, 13-5
4-9
4-10
5-59
5-86
5-104
5-106
6-14
13-1
DC power model added.
The tightening torque of the terminal screw changed. 0.4N•m or less→0.4 to
0.6 N•m or less.
Resistor type SSR added.
Connection method for the motor drive relay output(R1) added.
Note about CT1/2 heater burnout/over-current and short-circuit added.
Contents about unit added in the table.
Setting 0 and an explanation added in the table. Handling Precautions added.
Handling Precautions added.
Remarks about C42 to C45 added.
A standard of temperature sensor about input type added.
May 2005 3
3-4
5-2
5-5
5-13
5-18
5-23
5-24
5-25
5-38
5-51
5-62
5-63
5-85
5-87
5-88, 5-89
5-90, 5-91
5-92 to 5-113
6-14, 6-15
6-18
6-19
7-3 to 7-5
9-2, 9-3
10-2
10-3 to 10-4
13-1
13-3
13-5 to 13-7
13-6
Mounting procedures 2nd contents changed.
PV input range table *1,*2 added.
Handling Precautions explanation added.
MV rate-change limit (Setting: Parameter oUtL) added.
Output viriation limit added.
Priorities for PID group change added.
Hysteresis for zone added.
Change point→50.0% changed.
SP ramp-up/ramp-down,explanation item added.
Event channel definitions Contents changed.
High and Low limits of MFB value added. Note *1 added.
Handling Precautions added.
Output type Contents No. 10,11 added. explanation 2 item.
MV scaling range added.
Old 5-87 to 5-89 pages.
Number of CT turns and number of CT power wire loops added.
Old 5-89 to 5-110 pages.
C46, 51, 56 added. Handling Precautions added.
C90 to 93 added. Handling Precautions added.
Display E1.C1 Contents 33 added. Handling Precautions added.
Device ID code changed to Device code.
Control output 1, 2 and Auxiliary output 3 MV scaling added.
Alarm displays and corrective action AL11 added. Handling Precautions added.
Old 10-2 to 10-3 pages.
A standard of temperature sensor about input type added. DC voltage input
Input impedance added.
Current transformer input changed.
Old 13-4 to 13-6 pages.
Non-detected power failure time added.
Sep. 2005 4
4-5
4-7
5-73
6-10
13-1
Digital input circuit diagram changed.
Constant current type added.
Contents 44 (AL01 to AL99) added. Contents 45 (AL01 to AL03) added.
Display CYU, CY2 Remarks changed.
Diameter of the applicable thermocouple or compensating wire added.
