Azbil C35 Series User Manual

Date Rev. Revised pages Description
Aug. 2008 11
v
13-1
13-2
Manual No. CP-UM-5289E to CP-UM-5289JE changed.
Sampling cycle time 0.1s to 100ms changed.
Input impedance of voltage input specifications:
Max. 1MΩ to min. 1MΩ changed.
Current input specifications:
Allowable input current and allowable input voltage added.
June 2009 12
End paper
i, 1-1, 13-6
D-6
2-3
3-1
4-10
4-12
5-34, 5-35
5-37
5-38
5-39
5-107
6-10
7-5
7-6
7-7 to 7-18
7-17
7-18
13-1, 13-2
End of book
RESTRICTIONS ON USE deleted.
Standards compliance: “EN61326” changed to “EN61326-1.”
Parameter bank note *1 was changed.
Description of key operation corrected.
Installation locations: item added.
“Connection with current-input type controllers” section added.
“Noise preventive measures” section was moved to page 4-11.
Old page 4-11.
“RSP ratio and RSP bias” and “RSP filter” sections: “Standard” was added to the
User level.
“SP ramp unit” section was moved to page 5-38.
SP ramp-up/ramp-down: Explanation added.
SP multi-ramp: “High function” was added to the User level.
“Modutrol motor” was changed to “motor.”
User level for RSP filter and RSP bias: “0” changed to “1.”
Command details were added to the sample message.
“Application layer” section was moved from page 7-5.
Old page 7-6 to 7-16.
“Compiling” section added.
“Running the sample program” section added.
“Prosessing of the sample program” sections were moved from page 7-17.
• Thermocouple (T/C) input,
• Resistance temperature detector (RTD) input and • DC voltage input:
Allowable input voltage wore added.
Terms and Conditions added.
Nov. 2010 13
iii
2-3
4-1
5-26
5-110
13-4
2nd WARNING: Explanation changed.
Figure was changed.
1st WARNING: Explanation changed.
AT type: Initial value changed from 0 to1.
3rd motor auto adjusting procedure: 4th item partly deleted.
4th motor auto adjusting procedure: Description added to 3rd item
• Motor drive relay output (R1 model):
Description added to contact type
• Voltage pulse output (For SSR drive):
Description added to allowable current

Azbil C35 Series Specifications

General

Brand	Azbil
Model	C35 Series
Category	Controller
Language	English
