5-36
Chapter 5. DETAILED DESCRIPTION OF EACH FUNCTION
PID group number
The PID group numbers to the RSP and eight groups of LSPs can be set.
Item (Bank) Display Contents Initial value User level
PID group No. (RSP)
(SP bank)
1 to 8 1 Standard,
High function
PID group No. (LSP)
(SP bank)
1
1
1
1
1
1
1
1
• When the model provides the RSP input, the PID group number (RSP) can be
displayed and set.
• The PID group numbers (LSP) for the LSP system groups selected in [
C30
: LSP
system group] can be displayed and set.
LSP group number
The LSP group number can be set.
Item (Bank) Display Contents Initial value User level
LSP group No.
(Operation display)
Numeric value at the rightmost digit of the
display.
1 to LSP system group
1 Basic,
Standard,
High function
• When [
C30
: LSP system group] is set at “2” or more and [bit 2: LSP group
number display] of the PV/SP display setup (setup
C74
) is set at “1” (display is
provided), the display can be made.
• When the display is possible and the DI Assignment of the LSP group selection is
not performed, the setting can be made.
