Pro-Stcher User Manual Installaon | 3.9
4. Align the new Y-Encoder circuit board so the ve pins
on the encoder t into the ve-pin connector on the
circuit board and gently push into posion. The screw
hole on the circuit board should match up with the
hole in the encoder housing.
5. Replace the Phillips screw.
6. Plug the stch regulator cable into the new Y-encoder circuit board.
