INTRODUCTION
INSTRUCTION CONTENT
I-E96-192-5A 1 - 5
The hardware of the environmental OIC console is separated
into the upper and lower half of the cabinet. The CPU and
monitor are located in the top of the cabinet. The power entry
panel and MKM module are in the lower half of the cabinet
with the power supply. The annunciator display panel and
monitor are on the front of the cabinet. The alarm relays are
for alarm annunciation only.
A sealed air conditioner provides internal cooling and the
stainless steel exterior provides corrosion protection.
IIOIC424 Panel Mounted
The hardware of the panel mounted OIC console is located
behind the monitor and keyboard interface assembly. The
power supply, power entry panel, CPU and MKM module are
located with the monitor. The keyboard interface assembly is
mounted on a separate panel. The alarm relays are for alarm
annunciation only.
INSTRUCTION CONTENT
Introduction
Presents an overview of the OIC consoles and related hard-
ware. It also provides a complete list of specifications.
Description and
Operation
Describes the theory of operation of the OIC consoles and
related hardware.
Installation
Describes the installation and cabling. It also describes the
jumper settings of the multibus modules and peripherals. Be
sure to read and follow all warnings and cautions.
Troubleshooting
Lists troubleshooting steps and provides a troubleshooting
guide.
Maintenance
Contains a schedule and procedures for maintenance.
Component Description
and Replacement
Describes the hardware associated with the OIC42 and
replacement procedures for that hardware.
Support Services
Includes a spare parts list and ordering instructions.
Quick Reference
Information
Contains jumper and switch settings and fuse locations.
HOW TO USE THIS INSTRUCTION
Read this entire instruction through in sequence before
attempting to install or use the console. It is important to
become familiar with the entire content of the instruction prior
to installing and operating the console to attain maximum sys-
tem efficiency.
