INTRODUCTION
NOMENCLATURE
I-E96-192-5A 1 - 7
NOMENCLATURE
Table 1-4 contains the nomenclature used in this instruction.
OIC CONSOLE SPECIFICATIONS
Table 1-5 contains the specifications for the OIC Console.
Table 1-4. Hardware Nomenclature
Nomenclature Description
IIAKB04 QWERTY style auxiliary (engineering) keyboard.
IIAMS04 Mouse cursor controller.
IIATB05 Trackball cursor controller.
IIMKM02A Multibus keyboard module.
IIOIC421 Tabletop operator console with a 19-inch monitor, tilt/
swivel base and keyboard.
IIOIC4221 Console style operator console with a lower mounted
19-inch monitor and keyboard.
IIOIC4222 Console style operator console with an upper
mounted 19-inch monitor with tilt swivel base and
keyboard.
IIOIC423 Environmental operator console with a 19-inch moni-
tor and keyboard.
IIOIC424 Panel mount operator console with a 19-inch monitor
and engineering keyboard.
Table 1-5. OIC Console Specifications
Property Characteristic/Value
Power
Line voltage
Line frequency
Circuit breaker size
240 V nominal (180 VAC to 264 VAC RMS)
120 V nominal (90 VAC to 132 VAC RMS)
47 to 63 Hz
20 A circuit breaker for IIOIC422 and IIOIC423 consoles
10 A circuit breaker for IIOIC421 and IIOIC424 consoles
Power characteristics
Model
Inrush Current
Amps Typical
Crest Factor
Power Factor
Typical
IIOIC421 42 2.96 0.610
IIOIC4221 42 2.34 0.730
IIOIC4222 42 2.34 0.730
IIOIC423 42 1.95 0.843
IIOIC424 42 2.96 0.610
