COMPONENT DESCRIPTION AND REPLACEMENT
POWER ENTRY PANEL
I-E96-192-5A 6 - 11
degauss switch to correct picture distortion due to magnetic
fields on the screen of the lower monitor.
The system reset pushbutton resets the OIC multibus key-
board module (IIMKM02A) to an initial power up condition
when pressed.
A terminal block connects annunciators to user-defined
alarms. The terminal designation is printed on the panel
beside the terminal. The digital in (DI) and digital out (DO) ter-
minals are not used.
The power indicator is lit when the AC power is connected to
the power entry panel and the main power circuit breaker is
on.
Either 120 or 240-VAC power is used to supply power to the
IIOIC42 operator interface console. The AC in is either hard
wired (IIOIC422 model) or uses a 3-prong plug connector on
the power entry panel.
NOTES:
1. Use the AC outlet for the intended purpose only.
2. Refer to Section 3 for wiring and cable connections. Some of
the connections are on the back of the power entry panel and are
accessed through the door on the back of the OIC console.
IIOIC422 Console
To remove the power entry panel from an IIOIC422 console,
see Figure 6-9 and follow these steps:
1. Turn off the main circuit breaker on the power entry panel.
Check the power indicator to see if power is removed.
2. Shut down AC line power to cabinet (plant breaker) so that
the AC line may be disconnected safely.
3. Remove all cables from the front of the power entry panel.
4. Remove AC cables from the outlets on the power entry
panel.
5. Remove the signal cable from the multibus keyboard mod-
ule that goes to the rear of the power entry panel. Leave the
cables on the power entry panel. The new power entry panel
comes with cables.
6. Remove the five screws from around the front of the power
entry panel. Slide the power entry panel out the front of the
cabinet.
