Bailey 40 Series - IIOIC424 Panel Mount (CPU Removal)

COMPONENT DESCRIPTION AND REPLACEMENT
CPU REMOVAL
I-E96-192-5A 6 - 29
CPU ASSEMBLY
When assembling a new CPU, refer to Figure 6-21 for connec-
tor callouts and to the appropriate figure in Section 3 for the
cable connections for the model OIC being used.
Figure 6-20. CPU Removal for IIOIC424
Panel Mount Console
MONITOR
POWER ENTRY PANEL
CPU MOUNTING SCREWS
TP36162D
CPU
KEYBOARD
PORT
MOUSE
PORT
ETHERNET
NETWORK CABLE
AUX AC ON/OFF
POWER
SWITCH
