INTRODUCTION
I-E96-192-5A A - 1
APPENDIX A - QUICK REFERENCE INFORMATION
INTRODUCTION
This section provides a source for reference information. It
contains the jumper and switch settings and fuse locations for
the OIC42 operator interface console.
Figure A-1. IIMKM02A Multibus Keyboard Module
TP80571A
POWER CONNECTOR FOR
IIMKM02A WHEN USED ON THE
IIOIC421, IIOIC423 AND IIOIC424.
NOT USED IN IIOIC422.
CONNECT 8 PINS VERTICALLY - DATA
TRANSMITTED FROM PIN 2, RECEIVED
ON PIN 3.
CONNECT 8 PINS HORIZONTALLY -
DATA TRANSMITTED FROM PIN 3,
RECEIVED ON PIN 2.
NOT USED
NOT
USED
2-3 TOUCH SCREEN USE
1-2 RESET ON TIME-OUT
2-3 NO RESET ON TIME-OUT
1-2 DISABLE OOT SIGNAL
2-3 ENABLE OOT SIGNAL
P3
J4
J5
P15
P14
P17
P18
J3
J2
J1
P16
P6
P7
P8
P9
P5
P4
123
123
123
123
123
123
3
2
1
J9 J7
J6
J8
