Bailey 40 Series - CPU Removal for IIOIC421 Tabletop Console

COMPONENT DESCRIPTION AND REPLACEMENT
CPU REMOVAL
6 - 26 I-E96-192-5A
®
Figure 6-17. CPU Removal for IIOIC421
Tabletop Console
REAR VIEW OF
MONITOR
KEYBOARD INTERFACE
ASSEMBLY
CPU
CPU MOUNTING PLATE
RETAINING SCREWS
REAR VIEW (DOORS REMOVED)
TP36161C
KEYBOARD
PORT
MOUSE
PORT
ETHERNET
NETWORK CABLE
AUX AC ON/OFF
POWER
SWITCH
