INSTALLATION
OIC INSTALLATION
3 - 6 I-E96-192-5A
®
Follow local wiring codes when wiring and installing cableways
or conduit. For more information, refer to the Site Planning
and Preparation instruction.
IIOIC421 Tabletop Installation and Setup
The IIOIC421 tabletop model is normally used with a floor
mounted cabinet. The descriptions and procedures in this sec-
tion apply only to the tabletop unit and do not apply to the
cabinet. Figure 3-1 shows the dimensions of the OIC tabletop
model.
IOIC421 Tabletop Wiring Connections and Cabling
The IIOIC421 tabletop operator interface console is internally
wired when it is shipped. Connect the AC power and any periph-
eral devices. AC power input connects to the power connector on
the rear of the keyboard interface assembly (Figure 3-2).
Figure 3-3 shows cabling requirements. The circled numbers
illustrate the cables. Those numbers are called out in Table 3-2
which contains a description of the cabling connections.
Green -Remote voltage sense signal wire
White +Remote voltage sense signal wire
Table 3-1. OIC Wiring Color Codes
(continued)
Color Function
WARNING
Verify all covers are installed and all doors are closed before
operating the console. Exposed electrical connections present
a shock hazard that can cause injury or death.
AVERTISSEMENT
Assurez-vous que tous les couvercles sont installés et toutes
les portes fermées avant de faire fonctionner la console.
L´exposition à des connexions électriques presénte un risque
de blessure ou d´électrocution fatale.
