OIC CONSOLE SPECIFICATIONS
1 - 8 I-E96-192-5A
®
Power consumption
Power supply +5 VDC at 20 A, +12 VDC at 4 A, -12 VDC at 4 A
Keyboard Interface
Alarm relays
Alarm tones
Operator keyboard output relays rated at 250 mA 24-28 VDC per IIMKM02A
module.
6 per keyboard
5 per keyboard
Keyboards 1 Mylar (operator)
1 Engineering (QWERTY)
Annunciator display
panels
4 (per IIMKM02A module) 32 pushbuttons and LEDs per panel
Environment
Temperature
Relative humidity
Altitude
Operating: 10° to 40°C (50° to 104°F)
Nonoperating
1
: -30° to 65°C (-22° to 149°F
Storage: 5
°
to 50°C (41° to 122°F)
Operating: 20% to 80% noncondensing
Recommended minimum: 40%
Storage: 10% to 90% noncondensing
-0.3 to +2.4 km (-0.2 to 1.5 mi)
Cooling requirements
(Heat dissipation)
Table 1-5. OIC Console Specifications
(continued)
Property Characteristic/Value
Model Voltage
Typical
Amps
Maximum
Amps
Typical
Watts
Maximum
Watts
IIOIC421 120 1.96 2.55 175 227
240 1.20 1.56 175 227
IIOIC4221 120 1.80 2.34 158 205
240 1.11 1.44 162 211
IIOIC4222 120 1.80 2.34 158 205
240 1.11 1.44 162 211
IIOIC423 120 3.95 5.14 401 521
240 1.93 2.51 392 510
IIOIC424 120 1.96 2.55 175 227
240 1.20 1.56 175 227
Alarm Relays Rating
Contact Voltage 24 VDC
Contact Current 0.25 A
Contact Power 6 W
Model
BTU/Hr
Nominal
BTU/Hr
Maximum
IIOIC421 598 775
IIOIC4221 540 700
IIOIC4222 540 700
IIOIC423 1,339 1,742
IIOIC424
598 775
