INSTALLATION
OIC INSTALLATION
3 - 10 I-E96-192-5A
®
Protect the wires and cabling going to the OIC console. Run
cabling through conduit to the rear of the cabinet or under the
floor through the bottom of the cabinet. Follow local wiring
codes when wiring and installing cableways or conduit. Refer
to the Site Planning and Preparation instruction for more
information.
Figure 3-4. IIOIC422 Console Dimensions
2
1
TP80547A
2
1
HIGH MONITOR
LOW MONITOR
MOUNTING
MODEL
IIOIC4222
IIOIC4221
711.2
28.00
1085.7
42.75
1568.3
61.74
724.6
28.527
471.8
18.575
830.4
32.693
1090.1
42.918
DIMENSIONS
MILLIMETERS
INCHES
STUD
CENTER
482.6
19.00
66.0
2.60
281.8
11.09
TO REAR
DOOR
STUD CENTER
493.8
19.44
108.7
4.28
108.7
4.28
