INTRODUCTION
I-E96-192-5A 3 - 1
SECTION 3 - INSTALLATION
INTRODUCTION
This section explains how to install and prepare the OIC con-
soles. This section is a guide for the system engineer or techni-
cian. Follow the procedures in this instruction carefully to
install, maintain and use the system properly. Elsag Bailey
recommends reading the entire instruction before beginning
the installation and powering up the console.
For other installation information, refer to the Site Planning
and Preparation instruction and the appropriate OIS instruc-
tion. Refer to Table 1-3 for the instruction number.
SPECIAL HANDLING
Observe these steps when handling electronic circuitry:
NOTE:
Always use the Elsag Bailey Field Static Kit (part number
1948385
1) consisting of two wrist straps, ground cord assembly,
alligator clip, and static dissipating work surface when working with
static sensitive devices. The kit is designed to connect the techni-
cian and the static dissipating work surface to the same ground
point to prevent damage to the static sensitive devices by electro-
static discharge.
Use the static grounding wrist strap when installing and
removing modules. Static discharge may damage static sensi-
tive devices on modules in the cabinet. Use grounded equip-
ment and static safe practices when working with static
sensitive devices.
1. Use static shielding bag. Keep the modules in static
shielding bag until you are ready to install them in the system.
Save the bag for future use.
2. Ground bags before opening. Before opening a bag con-
taining an assembly with static sensitive devices, touch it to
the equipment housing or ground to equalize charges.
3. Avoid touching circuitry. Handle assemblies by the
edges; avoid touching the circuitry.
4. Avoid partial connection of static sensitive devices.
Verify that all devices connected to the modules are properly
grounded before using them.
5. Ground test equipment.
