229
www.balluff.com
3
Configuration Using Barcodes
Balluff BVS HS-P Family
Industrial Handheld Barcode Readers
Bluetooth HID
Variable PIN
Code
Specifies the selection available for Static or Variable Pin Code, when Bluetooth HID profile is con-
figured.
Some Bluetooth drivers on the Host (such as WIDCOMM and BlueSoleil 8) require a Variable PIN
Code. When attempting connection, the application presents a window that includes a PIN Code
which is to be input using the BVS HS-PB. Scan the barcode "Variable PIN Code" below, then
use the host computer’s Bluetooth manager to “Discover new devices” and select "Balluff
Reader." Use a text editor to see incoming data on the port designated by the computer's Blue
-
tooth manager.
When you hear the beep and see the Green LED blinking indicating the reader is waiting for an
alphanumeric entry, enter the required variable PIN Code by reading the corresponding barcodes
in
Appendix D: Keypad for alphanumeric entry. Finish by reading the Exit HID Variable PIN Code
label.
NOTE
If you receive an error message, it may be necessary to disable security on
the device.
Set Static Pin Code
Set Variable Pin code
CANCEL
Make a mistake? Scan the CANCEL barcode
to abort and not save the entry string. You
can then start again at the beginning.
Exit HID Variable PIN Code
To Next Page
