4.6.4 Aiming Duration
Time
Specifies the frame of time the aiming pointer remains on after decoding a label, when in trigger
single mode. The range for this setting is from 1 to 255 seconds in 1-second increments.
Follow these instructions to set this feature:
1 Determine the desired setting.
2 Pad the result with leading zeroes to yield three digits. For example: 0 = 000, 5 = 005, 20 =
020, etc.
3 Go to page 82 and scan the ENTER/EXIT PROGRAMMING MODE barcode to enter Pro-
gramming Mode.
4 Scan the barcode: SELECT AIMING DURATION TIME SETTING.
5 Scan the appropriate three digits from the keypad in Appendix D: Keypad, that represent the
duration which was determined in the steps above. You will hear a two-beep indication after
the last character.
6 Scan the ENTER/EXIT PROGRAMMING MODE barcode to exit Programming Mode.
This completes the procedure. See Table Aiming Duration Time Setting Examples for some
examples of how to set this feature.
Aiming Duration
Time Setting
Examples
NOTE
If you make a mistake before the last character, scan the CANCEL barcode to
abort and not save the entry string. You can then start again at the beginning.
STEP ACTION EXAMPLES
1 Desired Setting 1 Second
90 Sec.
(1.5 min.)
180 Sec.
(3 min.)
255 Seconds
(4.25 min.)
2 Pad leading zero(es) 001 090 180 255
3 Scan ENTER/EXIT PROGRAMMING MODE
4 Scan SELECT AIMING DURATION TIME SETTING
5
Scan Three
Characters From
Appendix D: Keypad
‘0’, ‘0’ and
‘1’
‘0’, ‘9’ and
‘0’
‘1’, ‘8’ and
‘0’
‘2’, ‘5’ and ‘5’
6 Scan ENTER/EXIT PROGRAMMING MODE
