Configuration Using Barcodes
Balluff BVS HS-P Family
Industrial Handheld Barcode Readers
3.8.7 EAN 8 (Jan 8) The following options apply to the EAN 8 (Jan 8) symbology.
EAN 8 Enable/
Disable
When disabled, the reader will not read EAN 8/JAN 8 barcodes.
EAN 8 Check
Character
Transmission
Enable this option to transmit the check character along with EAN 8 barcode data.
Expand EAN 8
to EAN 13
Enable this option to expand EAN 8/JAN 8 labels to EAN 13/JAN 13.
EAN 8 = Disable
EAN 8 = Enable
8BEN00(CR
8BEN01(CR
DEFAULT
EAN 8 Check Character Transmission =
Don’t Send
EAN 8 Check Character Transmission = Send
8BCT00(CR
8BCT01(CR
DEFAULT
Expand EAN 8 to EAN 13 = Disable
Expand EAN 8 to EAN 13 = Enable
DEFAULT
8B3B00(CR
8B3B01(CR
