References
Balluff BVS HS-P Family
Industrial Handheld Barcode Readers
4.6 Reading
Features
4.6.1 Scan Mode This mode is associated with typical handheld reader operation. Selects the scan operating mode
for the reader. The following selections are valid for all models:
Trigger Single: When the trigger is pulled, reading is activated until one of the following occurs:
- Reading Active Time has elapsed
- a label has been read
- the trigger is released
Trigger Hold Multiple: When the trigger is pulled, reading starts and the product scans until the
trigger is released or Reading Active Time has elapsed. Reading a label does not disable reading.
Double Read Timeout prevents undesired multiple reads of the same label while in this mode.
Trigger Pulse Multiple: When the trigger is pulled, continuous reading is activated until Reading
Active Time has elapsed or the trigger has been released and pulled again. Double Read Timeout
prevents undesired multiple reads of the same label while in this mode.
Flashing: The reader flashes on and off regardless of the trigger status. Flash rate is controlled by
Flash On Time and Flash Off Time. When Flash is ON the imager reads continuously; when
Flash is OFF reading is deactivated.
Always On: No trigger pull is required to read a barcode. reading is continually on. If the trigger is
pulled, the reader acts as if it is in Trigger Single Mode. Double Read Timeout prevents undesired
multiple reads of the same label while in this mode.
Stand Mode: No trigger pull is required to read a barcode. Reading is turned on automatically
when an item is placed in the reader’s field of view.
Double Read Timeout prevents undesired
multiple reads while in this mode.
