Balluff BVS HS-P Family
Industrial Handheld Barcode Readers
4.2 Keyboard
Interface
4.2.1 Wedge Quiet
Interval
Specifies the amount of time the reader looks for keyboard activity before it breaks the keyboard
connection in order to transmit data to host. The range is from 0 to 990ms in 10ms increments.
1 Determine the desired setting in milliseconds.
2 Divide the desired setting by 10 (setting is in 10ms increments). Pad the result with leading
zeroes to yield two digits. For example: 0 = 00, 5 = 05, 20 = 20, etc.
3 Go to page 50 and scan the ENTER/EXIT PROGRAMMING MODE barcode to enter Prog.
Mode.
4 Scan the barcode: SELECT WEDGE QUIET INTERVAL SETTING.
5 Scan the appropriate two digits from the keypad in Appendix D: Keypad, that represent the
duration which was determined in the steps above. You will hear a two-beep indication after
the last character.
6 Scan the ENTER/EXIT PROGRAMMING MODE barcode to exit.
This completes the procedure to set the Wedge Quiet Interval. See Table Wedge Quiet Interval
Setting Examples for some examples of how to set this feature.
Wedge Quiet
Interval Setting
Examples
NOTE
This feature applies ONLY to the Keyboard Wedge interface.
NOTE
If you make a mistake before the last character, scan the CANCEL barcode to
abort and not save the entry string. You can then start again at the beginning.
STEP ACTION EXAMPLES
1 Desired Setting 10ms 150ms 600ms 850ms
2
Divide by 10 (and pad
with leading zeroes)
01 15 60 85
3 Scan ENTER/EXIT PROGRAMMING MODE
4 Scan SELECT WEDGE QUIET INTERVAL SETTING
5
Scan Two Characters
From Appendix D:
Keypad
‘0’ and ‘1’ ‘1’ and ‘5’ ‘6’ and ‘0’ ‘8’ and ‘5’
6 Scan ENTER/EXIT PROGRAMMING MODE
