References
Balluff BVS HS-P Family
Industrial Handheld Barcode Readers
4.5 Reading
Parameters
4.5.1 Good Read LED
Duration
This feature specifies the amount of time that the Good Read LED remains on following a good
read. The good read LED on time can be set within a range of 10 milliseconds to 2,550 millisec
-
onds (0.001 to 2.55 seconds) in 100ms increments.
Follow these instructions to set this feature:
1 Determine the desired setting in milliseconds. A setting of 0 means that the good read LED
stays on until the next time the trigger is pulled.
2 Divide the desired setting by 10 (setting is in 100ms increments). Pad the result with leading
zeroes to yield three digits. For example: 0 = 000, 5 = 000, 20 = 020, etc.
3 Go to page 76 and scan the ENTER/EXIT PROGRAMMING MODE barcode to enter Pro-
gramming Mode.
4 Scan the barcode: SELECT GOOD READ LED DURATION SETTING.
5 Scan the appropriate three digits from the keypad in Appendix D: Keypad representing the
duration which was determined in the steps above. You will hear a two-beep indication after
the last character.
6 Scan the ENTER/EXIT PROGRAMMING MODE barcode to exit Programming Mode.
This completes the procedure. See Table Good Read LED Duration Setting Examples for some
examples of how to set this feature.
Good Read LED
Duration Setting
Examples
NOTE
If you make a mistake before the last character, scan the CANCEL barcode to
abort and not save the entry string. You can then start again at the beginning.
STEP ACTION EXAMPLES
1 Desired Setting
Good Read
LED stays on
until next
trigger pull
(00)
20ms 150ms
2550ms (2.55
sec.)
2
Divide by 10 (and pad
with leading zeroes)
000 002 015 255
3 Scan ENTER/EXIT PROGRAMMING MODE
4
Scan
SELECT GOOD READ LED DURATION SETTING
5
Scan Three
Characters From
Appendix D: Keypad
‘0’, ‘0’ and
‘0’
‘0’, ‘0’ and
‘2’
‘0’, ‘1’ and
‘5’
‘2’, ‘5’ and ‘5’
6 Scan ENTER/EXIT PROGRAMMING MODE
