Balluff BVS HS-P Series User Manual

87
www.balluff.com
3
Configuration Using Barcodes
Balluff BVS HS-P Family
Industrial Handheld Barcode Readers
3 Configuration Using Barcodes
3.8 1D Symbologies The reader supports the following 1D symbologies (barcode types). See "2D Symbologies" start-
ing on page 175 for 2D barcodes. Symbology-dependent options are included in each chapter.
Default settings are indicated at each feature/option with a green arrow. Also reference Appendix
C: Standard Defaults for a listing of the most widely used set of standard factory settings.
To set most features:
1 Scan the ENTER/EXIT PROGRAMMING barcode at the top of applicable programming
pages.
2 Scan the correct barcode to set the desired programming feature or parameter. You may need
to cover unused barcodes on the page, and possibly the facing page, to ensure that the
reader reads only the barcode you intend to scan.
3 If additional input parameters are needed, go to Appendix D: Keypad, and scan the appropri-
ate characters from the keypad.
4 Complete the programming sequence by reading the ENTER/EXIT PROGRAMMING barcode
to exit Programming Mode.
Disable All Symbologies, page 88 GS1-128, page 123
Code EAN/UPC, page 89 Code ISBT 128, page 124
UPC-E, page 92 Interleaved 2 of 5 (I 2 of 5), page 127
GTIN Formatting, page 94 Interleaved 2 of 5 CIP HR, page 132
EAN 13 (Jan 13), page 95 Follett 2 of 5, page 133
ISSN, page 97 Standard 2 of 5, page 134
EAN 8 (Jan 8), page 98 Industrial 2 of 5, page 138
UPC/EAN Global Settings, page 100 Code IATA, page 142
Add-Ons, page 101 Codabar, page 143
Code 39, page 107 ABC Codabar, page 149
Trioptic Code, page 112 Code 11, page 152
Code 32 (Ital Pharmaceutical Code), page 113 GS1 DataBar™ Omnidirectional, page 156
Code 39 CIP (French Pharmaceutical), page 115 GS1 DataBar™ Expanded, page 157
Code 39 Danish PPT, page 116 GS1 DataBar™ Limited, page 161
Code 39 LaPoste, page 117 Code 93, page 162
Code 39 PZN, page 118 MSI, page 167
Code 128, page 119 Plessey, page 171
NOTE
Additional information about many features can be found in the “References”
chapter.
If you make a mistake before the last character, scan the CANCEL barcode to
abort and not save the entry string. You can then start again at the beginning.
