4.6.6 Flash Off Time This feature specifies the OFF time for the indicator LED while in Flash Mode. The selectable
range is 100 to 9,900 milliseconds (0.1 to 9.9 seconds), in 100 millisecond increments.
Follow these instructions to set this feature.
1 Determine the desired setting in milliseconds.
2 Divide the desired setting by 100 (setting is in 100ms increments). Pad the result with leading
zeroes to yield two digits. For example: 0 = 00, 5 = 05, 20 = 20, etc.
3 Go to page 81 and scan the ENTER/EXIT PROGRAMMING MODE barcode to enter Pro-
gramming Mode.
4 Scan the barcode: SELECT FLASH OFF TIME SETTING.
5 Scan the appropriate two digits from the keypad in Appendix D: Keypad, that represent the
duration which was determined in the steps above. You will hear a two-beep indication after
the last character.
6 Scan the ENTER/EXIT PROGRAMMING MODE barcode to exit Programming Mode.
This completes the procedure. See Table Flash Off Time Setting Examples for some examples of
how to set this feature.
Flash Off Time
Setting
Examples
NOTE
If you make a mistake before the last character, scan the CANCEL barcode to
abort and not save the entry string. You can then start again at the beginning.
STEP ACTION EXAMPLES
1 Desired Setting 500ms
1,000ms
(1 sec.)
5200ms
(5.2 sec.)
9,900ms
(9.9 sec.)
2
Divide by 100 (and pad
with leading zeroes to
yield two digits)
05 10 52 99
3 Scan ENTER/EXIT PROGRAMMING MODE
4 Scan SELECT FLASH OFF TIME SETTING
5
Scan Two Characters
From Appendix D:
Keypad
‘0’ and ‘5’ ‘1’ and ‘0’ ‘5’ and ‘2’ ‘9’ and ‘9’
6 Scan ENTER/EXIT PROGRAMMING MODE
